Product details
Description
2. Embedded driver ST7735S, supports 65K colors
3. Onboard SRAM 23LC1024, used as display cache, no more out of memory
4. SPI interface, takes up only a few IO pins
5. Backlight adjustment via PWM
6. Reserved solder pads for control interface, make it easy to connect with Arduino/Nucleo boards
7. Driver: ST7735S
8. Resolution: 160x128
9. Color display: RGB, 65k colors
10. Operating voltage: 3.3 v
11. Dimension: 61 x 51.5mm
