Product details
Description
The Waveshare 2.13 inch E-Ink Display HAT is designed for use with Raspberry Pi devices. It is suitable for applications such as shelf labeling and industrial instruments due to its low power consumption and clear display capabilities.
- Product Type: E-Ink Display HAT
- Compatibility: Raspberry Pi Zero, Zero W, Zero WH, 2B, 3B, 3B+
- Material: Electronic components
- Display Size: 23.71mm x 48.55mm
- Resolution: 212 x 104 pixels
- Display Color: Red, Black, White
- Grey Level: 29
- Dot Pitch: 0.229 x 0.228 mm
- Operating Voltage: 3.3V/5V
- Interface: 3-wire SPI, 4-wire SPI
- Outline Dimension: 65mm x 30.2mm
- Full Refresh Time: 15 seconds
- Refresh Power: 26.4mW (typical)
- Standby Power: <0.017mW
- Viewing Angle: >170 degrees
- Includes development resources and manual for Raspberry Pi, Jetson Nano, Arduino, STM32
- Preserved solder pads for SPI interface for connecting with other controller boards
- Onboard voltage translator compatible with 3.3V/5V MCUs
- Package Contents: 2.13 inch e-Paper HAT (B), RPi screws pack (2pcs), PH2.0 20cm 8 Pin
